HD-VP2060 Video Processor
The HD-VP2060 Video Processor is a high-performance LED display controller designed for medium and large LED screen applications. Supporting up to 13.0 million pixels, it offers advanced video processing, multiple input interfaces, and reliable signal transmission. Its 20 Gigabit Ethernet ports and six-window display capability make it an excellent choice for digital signage, exhibitions, corporate events, and commercial LED display systems.
Specifications
| Feature | Specification |
|---|---|
| Model | HD-VP2060 |
| Loading Capacity | 13.0 Million Pixels |
| Maximum Width | 16,384 Pixels |
| Input Interface | DP 1.2, HDMI 2.0, 4 × HDMI 1.3 |
| Gigabit Ethernet Ports | 20 |
| Prefabricated Scenes | 16 |
| Wi-Fi | Supported |
| TRS Audio | Input / Output |
| Window Quantity | 6 |
| Central Control | USB-B, Wi-Fi, RS232, IR (Optional) |
Key Features
Supports up to 13.0 million pixels
Maximum display width of 16,384 pixels
20 Gigabit Ethernet output ports
DP 1.2 and HDMI 2.0 inputs
Six-window display support
Built-in Wi-Fi
16 preset scenes
TRS audio input/output
USB-B, RS232 & optional IR control
Reliable solution for professional LED display projects
