HD-VP10 Video Processor
The HD-VP10 Video Processor is a professional LED display controller designed for medium and large LED screen installations. Supporting up to 6.5 million pixels, it combines powerful image processing with flexible connectivity and stable performance. Equipped with multiple input interfaces, 10 Gigabit Ethernet output ports, and advanced control features, the HD-VP10 is perfect for digital signage, exhibitions, conference rooms, and commercial LED display applications.
Specifications
| Feature | Specification |
|---|---|
| Model | HD-VP10 |
| Loading Capacity | 6.5 Million Pixels |
| Maximum Width | 16,000 Pixels |
| Input Interface | 1 × DP 1.2, 1 × HDMI 2.0, 1 × HDMI 1.4, 1 × 3G SDI (Optional), 1 × USB, 1 × Audio |
| Output Interface | 10 × Gigabit Ethernet Ports, 1 × Audio |
| Window Quantity | 2 |
| Wi-Fi | Supported |
| Prefabricated Scenes | 256 |
| Central Control | USB-B, Wi-Fi, LAN, RS232, RS485, IR (Optional) |
Key Features
- Supports up to 6.5 million pixels
- Maximum display width of 16,000 pixels
- 10 Gigabit Ethernet output ports
- HDMI 2.0, DP 1.2 & optional 3G SDI input
- Dual-window display support
- Built-in Wi-Fi connectivity
- 256 preset scenes
- USB-B, LAN, RS232 & RS485 control
- Stable and reliable LED video processing
