H15 Modular Video Wall Processor
The H15 Modular Video Wall Processor is a flagship controller designed for ultra-large LED display installations. It supports 130 million pixels through RJ45 sending cards and up to 416 million pixels with the Enhanced optical fiber configuration. Featuring high-density modular expansion, advanced image processing, HDR support, and ultra-flexible routing, the H15 is ideal for mission-critical visualization environments.
Specifications
| Feature | Specification |
| Model | H15 |
| Rack Unit | 15U |
| Max Loading Capacity (RJ45) | 130 Million Pixels (Enhanced: 208 Million Pixels) |
| Max Loading Capacity (Fiber Enhanced) | 260 Million Pixels (Enhanced: 416 Million Pixels) |
| Max Input Cards | 30 |
| Max Output Cards | 10 (Enhanced: 16) |
| Maximum Output Resolution | 2560×2560 (Video Connector), 10752×10752 (RJ45), 16384×16384 (OPT) |
| Max Layers | 160 |
| Preset Scenes | 2000 |
| Irregular Mosaic | Supported |
| 10-bit & HDR | Supported |
| Input/Output Monitoring | Supported |
| Optional Power Supply | Supported |
| Permission Management | Supported |
| Central Control | TCP/IP, RS232 |
| OSD | Supported |
| Background (BKG) | Supported |
| Touch Panel Control | Supported |
Key Features
- Up to 416 million pixel capacity
- Professional modular architecture
- 160 independent layers
- HDR image processing
- 2000 preset scenes
- Enterprise-grade control system
